Filling station BG-L
Filling
Filling station BG-L
Filling station BG-L
Filling station BG-L
Filling station BG-L
Filling station BG-L
Filling station BG-L
Filling station BG-L
Filling station BG-L
Filling station BG-L
Filling station BG-L

Filling station BG-L

Filling

Description

The BG-L filling station from HECHT is designed so that it is easily accessible from three sides.
The L-shaped design favours loading the system with a hand pallet truck, so no forklift or crane is required. Handling when connecting the big bags is also made considerably easier.
A roller conveyor for filling small containers can be retrofitted.
The loop holders on the support frame are easily adjustable.


Customer benefits

  • Easy cleaning thanks to accessibility from three sides
  • Height-adjustable support frame (optional) with manual height adjustment via perforated strips or automatic height adjustment (with electric lifting spindle or pneumatic cylinder)
  • Available as Big Bag filling station BG-L in hygienic design
  • All types of filling heads can be used
  • Integration of a roller conveyor for filling drums or cartons
  • Folding pallet supports for easy cleaning
  • Integration of load cells
Enquire now

Technology

The empty big bag is hooked into the loop hook in an optionally height-adjustable support frame with manual height adjustment via perforated strips or automatic height adjustment (with electric lifting spindle or pneumatic cylinder).
The entire station can be placed on load cells for gravimetric filling. Different filling heads can be used depending on requirements.
The filled big bag is transported out of the station on a pallet using a forklift truck or hand pallet truck. The pallet supports can simply be folded upwards for cleaning. A roller conveyor can be attached for filling drums or sacks.
